उत्पाद का विवरण
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: E-link
प्रमाणन: ISO9001, CE, ROHS, FCC
मॉडल संख्या: LNK-1100WSFP
दस्तावेज: E-link LNK-1100 Series Medi....1.pdf
भुगतान और शिपिंग की शर्तें
न्यूनतम आदेश मात्रा: 1 टुकड़ा
मूल्य: negotiate
पैकेजिंग विवरण: मीडिया कनवर्टर मानक कार्टन पैकेजिंग
प्रसव के समय: 1-3 कार्य दिवस
भुगतान शर्तें: टी/टी, वेस्टर्न यूनियन, मनीग्राम, पेपैल
आपूर्ति की क्षमता: 1000/महीना
वेवलेंथ: |
850 एनएम / 1310 एनएम / 1550 एनएम |
रूपांतरण का अर्थ है: |
स्टोर और फॉरवर्ड मोड या कट-थ्रू मोड |
हिट: |
<19-9 |
बिजली की आपूर्ति: |
डीसी 5 वी / 1 ए |
बिजली की खपत: |
<40W (पूर्ण लोड पर चेसिस), <2w |
तापमान बनाए रखना: |
-40 ~ 70ºC |
वेवलेंथ: |
850 एनएम / 1310 एनएम / 1550 एनएम |
रूपांतरण का अर्थ है: |
स्टोर और फॉरवर्ड मोड या कट-थ्रू मोड |
हिट: |
<19-9 |
बिजली की आपूर्ति: |
डीसी 5 वी / 1 ए |
बिजली की खपत: |
<40W (पूर्ण लोड पर चेसिस), <2w |
तापमान बनाए रखना: |
-40 ~ 70ºC |
Model : LNK-1100 Series
Overview
The 10/100M Fast Ethernet Media Converter (with External Power Supply) SFP Slot
(LNK-1100 Series) is a professional network conversion solution engineered for seamless
signal transition between copper and fiber media. As a 10/100M Fast Ethernet Media
Converter (with External Power Supply) SFP Slot, it excels in inter-converting electrical
signals from 10Base-T/100Base-TX twisted pairs with optical signals from 100Base-FX,
ensuring stable data transmission across different network infrastructures.
Features
► 10/100Mbps auto-sensed, facilitating network upgrade
► full-duplex and half-duplex auto-sensed
► Supporting auto-sense of MDI/MDI-X, facilitating system commissioning and installation
► Supporting 10/100Mbps store-and-forward and 100Mbps cut-through transmission with optional dip-switch
► Supporting Quality of Service (QoS) , ensuring the transmission of VoIP packets
Options in single mode dual fiber, multi-mode dual fiber, and single mode in
Technical Indexes
|
Parameter |
Specifications |
|
Access mode |
10/100Mbps |
|
Standard |
IEEE802.3 10Base-T Ethernet, IEEE802.3u,100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control |
|
Wavelength |
850nm/1310nm/1550nm |
|
Transmission distance |
Dual-fiber multi-mode: 2 km; Dual-fiber single mode: 20/40/60/80/100/120 km; Single fiber single mode: 20/40/60/80/100 km Category-5 twisted pairs: 100m |
|
Port |
One RJ45 port: for connecting STP/UTP category-5 twisted pairs One optical port: Multi-mode, dual fiber: SC or ST (50, 62.5/125μm) Single mode, dual fiber: SC or FC (9/125μm) Single mode Single fiber: SC or FC (9/125μm) |
|
Conversion means |
Store and Forward mode or Cut-Through mode |
|
Buffer space |
Built in 128Kb RAM for data buffer |
|
Flow control |
Full duplex: flow control; Half duplex: back pressure |
|
BER |
<19-9 |
|
MTBF |
100,000 hours |
|
LED indicator |
POER (power supply); FX LINK/ACT (optical link action); FDX (FX full duplex), TX LINK/ACT (TP cable link/action); TX 100 (TP cable rate 100M), FX100(fiber cable rate 100M) |
|
Power supply |
DC 5V / 1A |
|
Power consumption |
<40W (the chassis at full load), <2W |
|
Operating temperature |
-10~55ºC |
|
Operating humidity |
5%~90% |
|
Maintaining temperature |
-40~70ºC |
|
Maintaining humidity |
5% ~ 90% non-condensing |
|
Dimensions (W x D x H) |
71 x 94 x 26 mm |
Ordering Information
|
Item |
Description |
|
LNK-1100 |
10/100Base-T to 100Base-F, multi-mode, 2km, 1310nm, SC, standalone, external power adaptor |
|
LNK-1100S-20 |
10/100Base-T to 100Base-F, single mode, 20km, 1310nm, SC, standalone, external power adaptor |
|
LNK-S1100-20 |
10/100Base-T to 100Base-F, WDM(single fiber bi-direction), 20km, 1310/1550nm, SC, standalone, external power adaptor |
